3/8" Cooling Kit with 24 Nozzles (50-ft hose with 19 2-ft segments)
Cool off your outdoor living area with this Do-It-Yourself Misting Kit. This high quality system comes complete with 24 brass nozzles that deliver a continuous stream of ultra-fine mist, which can cool the ambient temperature up to 25°F. With a normal hose pressure between 40 and 80 PSI.Within that pressure the flow rate per nozzle is between .4 and .5 gallons per hour each
Features
· Reduces temperature up to 25°F
· Connects to your standard faucet/spigot
· Premium brass nozzles that are rust free and more resistant to calcium deposits
· High quality UV-resistant material
· Cools patios, play and pet areas
· Clears airborne particles and repels flying insects
· Easy to install
· Fully expandable
· Helps humidify during the dry season
· Coverage area: approximately 15 sq.ft. per nozzle
· Made in the USA
Contents:
· 3/8″ Hose (50-foot) x 1
· 3/8″ Hose (2-foot segments) x 19
· Premium Brass Nozzles & O rings x 24
· Nozzle Plugs & O rings x 4
· 3/8″ Misting Tees x 20
· 3/8″ Misting Elbows x 4
· 3/8″ Compression Tees x 4
· 3/8″ Compression Elbows x 4
· 3/8″ Compression Couplers x 4
· 3/4″ Hose Thd x 3/8″ Adapter x 1
· 3/8″ Wood Mounting Clamps x 50
· Poly-Phosphate Filter x 1
· 3/4″ Y-Connector x 1
5 Easy Steps to Efficient Misting:
Attach the Adapter to your outdoor faucet. Insert one end of the 50′ hose to adapter (about 1/4″). Cut hose to the desired length to reach the first Compression Tee, Elbow or Misting Tee
*Note: The included water filter attaches between the kit tubing.
Push and twist the hose about 1/2″ into ends of Compression Tees, Elbows, Couplers and Misting Tees. Install the Misting Elbow at the end of the system. The recommended distance between misting nozzles is 2 feet.
Turn on the water to flush out the system before installing Misting Nozzles
Nail Mounting Clamps close to the Nozzle Tees and Elbow. Use protective eye wear
Carefully install the Misting Nozzles. Make sure “O” ring is properly seated. Hand tighten only. Rotate Misting Nozzles to desired angle
